Introduction

The YUNLEA 5.0-inch TFT LCD with integrated capacitive touch panel is a high-performance display solution designed for industrial, commercial, and consumer applications. With ultra-bright backlight, wide operating temperature range, and responsive multi-touch technology, this module delivers a superior user experience even in demanding environments.


Key Features

📺 5.0” TFT LCD + Capacitive Touch Panel

Compact size with excellent display clarity, ideal for handheld devices, embedded systems, and medical equipment.

🎨 High Resolution & Vivid Colors

  • 800 × 480 pixels with RGB stripe arrangement

  • Supports up to 16.7M colors

  • Provides vibrant, sharp, and accurate image performance

☀️ Ultra Brightness

  • Equipped with 27 white LEDs

  • Up to 1000 nits luminance (with CTP)

  • Ensures excellent visibility under direct sunlight

✋ Advanced Touch Technology

  • G+G structure with GT911 capacitive touch IC

  • Supports multi-touch gestures and smooth operation

  • I²C interface for reliable and fast communication

👀 Wide Viewing Angle

All O’Clock viewing direction ensures consistent clarity from any angle.

🛡️ Robust Design & Reliability

  • Operating temperature: -30°C to +85°C

  • Storage temperature: -30°C to +85°C

  • LED lifetime: 30,000 hours
    Ensures stable performance in harsh industrial and outdoor environments.

🔧 Easy Integration

  • TFT Driver IC: GH7006

  • Interface: 24-bit RGB

  • Module size: 136.0 × 92.8 × 4.55 mm (with CTP)


Applications

The YUNLEA 5.0-inch LCD + CTP module is suitable for:

  • Industrial control panels

  • Automotive displays

  • Smart home devices

  • Medical instruments

  • Handheld terminals

  • POS and self-service kiosks


Why Choose YUNLEA?

With years of expertise in touch display technology, YUNLEA provides customizable, reliable, and high-performance display solutions. Our engineering team offers flexible customization for brightness, interfaces, and touch technology to match your project’s requirements.

📩 Contact us at info@yunlea.com for more details or to request samples.
